How to build a chalkboard

by Jack Sander
0 comments 143 views 4 minutes read



This step by step diy woodworking project is about how to build a chalkboard. If you want to learn more about building a chalkboard, we recommend you to pay attention to the instructions described in the article. There are so many chalkboard plans and designs to choose from, so make sure you take a close look over the rest of the related woodworking projects that are featured on our website.

Before starting the actual construction project, we recommend you to plan everything, as to save money and to keep the costs under control. Adjust the size and the design of the chalkboard to suit your needs. In addition, we recommend you to invest in high-quality materials, such as pine, redwood or cedar, as they have a nice finish and are highly durable, especially in a humid environment.

If you don’t have a rich expertise in woodworking field, you should ask a friend to give you a hand with the project. There are many things that you could go wrong, so make sure you plan everything and invest in quality materials. Select the lumber with attention, making sure the components are perfectly straight and in a very good condition. Use a carpentry square to check if the corners are right-angled. See all my Premium Plans in the Shop.



Made from this plan

Add-Image



How to build a chalkboard

Building a chalkboard shelf

Building a chalkboard shelf



Materials

  • A – 4 pieces of 1×12 lumber – 24″ long BOARD
  • B – 2 pieces of 1×2 lumber – 24″ long, 1 pieces – 12 3/4″ long TRIMS
  • C – 1 piece of 1×4 lumber – 12 3/4″ long SHELF
  • D – 2 piece of metal hooks HOOKS

  • 1 piece of 1×12 lumber – 1 ft
  • 1 piece of 1×2 lumber – 6 ft
  • 1 piece of 1×4 lumber – 2 ft
  • hooks
  • 2 1/2″ screws
  • 1 1/4″ screws
  • glue, stain
  • wood filler

Tools

  • Safety gloves, glasses, Miter saw, jigsaw
  • Chalk line, tape measure, spirit level, carpentry pencil
  • Drill machinery and drill bits

Tips

  • Apply several coats of wood stain to the wooden components
  • Fill the holes with wood filler and smooth the surface

Time

  • One Day

Related





Building a chalkboard

Building the chalkboard sheet

Building the chalkboard sheet



The first step of the woodworking project is to build the board out of 1×12 lumber. Mark the cut lines on the piece of lumber and get  the job done using a circular saw. Smooth the cut edges with sandpaper and remove the residues using a cleaner. Afterwards, apply chalkboard spray paint to the board and let it dry out for several hours.



Fitting the trims

Fitting the trims



The next step of the project is to attach the 1×2 trims to the chalkboard, as shown in the diagram. Cut the trims at the right size and secure them to the chalkboard using 1 1/2″ finishing nails and waterproof glue. Smooth the exposed edges and remove the residues.



Building the shelf

Building the shelf



Build the shelf out of 1×4 lumber. Mark the cut lines on the piece of lumber and create the notches using a circular saw. Smooth the cut edges using sandpaper and drill pocket holes, as described in the diagram.



Fitting the shelf

Fitting the shelf



Attach the shelf to the chalkboard, align it at both ends and secure it to the structure by using 1 1/4′ screws. Add glue to the joints and make sure there are no gaps between the components.



Fitting the hooks

Fitting the hooks



One of the last steps of the project is to attach the hooks to the bottom of the chalkboard. Align the hooks with attention, in order to make sure the chalkboard will have a symmetrical appearance.

Last but not least, you need to take care of the final touches. Therefore, you need fill all the holes with a good filler and let the compound to dry out properly, before sanding the wooden surface with 120-grit sandpaper.

Smart Tip: Clean the residues with a dry cloth, before staining the chalkboard with the appropriate products for your tastes and needs.





Thank you for reading our article about how to build a chalkboard and we recommend you to check out the rest of our home improvement projects. Don’t forget to LIKE and SHARE this projects to your friends, using the social media widgets, if you’ve found it useful.
