This diy step by step diy project is about tool stand plans. This project is about building a simple tool stand with caster wheels and with storage shelves. Anyone can get the job done, as the project requires basic tools and materials. This makes for a handy project that will add value to your workshop and ease your work.

You should always plan everything from the very beginning, in order to prevent costly mistakes and to save time. If this is your first project, you should read the instructions with attention. Invest in high quality lumber and plywood, as the components will be exposed to bad weather. Protect the components with appropriate paint or stain.

There are a few tips that you should take into account, if you want to get a professional result. Therefore, take accurate measurements and use professional tools when making the cuts or when drilling pilot holes. Align the components at both ends and add waterproof glue to the joints, if you want to create a rigid structure. See all my Premium Plans in the Shop.





Made from this plan

Add-Image







Tool Stand Plans

Building a tool stand

Building a tool stand



Materials

  • A – 4 pieces of 2×2 lumber – 34″ long LEGS
  • B – 1 piece of 3/4″ plywood – 19 3/4″x34″ long, 2 pieces – 24″x34″ long PANELS
  • C – 8 pieces of 1×2 lumber  – 24″ long CLEATS
  • D – 3 pieces of 3/4″ plywood – 21 1/4″x24″ long SHELVES
  • E – 1 piece of 3/4″ plywood – 31 3/4″x36″ long, 2 pieces of 1×2 lumber – 33 1/4″ long, 2 pieces – 37 1/2″ long TABLETOP

  • 1 piece of 2×2 lumber – 12 ft
  • 4 pieces of 1×2 lumber – 8 ft
  • 2 pieces of 3/4″ plywood – 4’x8′
  • 1 1/4″ brad nails
  • 1 1/4″ screws
  • stain, glue, putty

Tools

  • Safety gloves, glasses
  • Miter saw, jigsaw, pocket hole jig
  • Chalk line, tape measure, spirit level, carpentry pencil
  • Drill machinery and drill bits

Tips

  • Use a good miter saw to make the angle cuts
  • Drill pilot holes before inserting the screws

Time

  • One Day

Related





How to build a tool stand

Building the panels

Building the panels

The first step of the project is to build the panels for the tool stand. Cut the components from 3/4″ plywood. Drill pocket holes along the sides of the panels, as shown in the diagram. Make two 24″ wide pieces and one 19 3/4″ wide piece.

Assembling the tool stand

Assembling the tool stand

Build the legs for the tool stand from 2×2 lumber. Align the panels to the legs and lock them together with 1 1/4″ screws. Add glue to the joints and remove the excess with a damp cloth.

Fitting the supports

Fitting the supports

Fit the 1×2 supports to the interior of the tool stand, as shown in the diagram. Use glue and 1 1/4″ brad nails to secure it to the panels.

Fitting the trims to the back of the stand

Fitting the trims to the back of the stand

Fit 1×2 trims to the back of the tool stand, as shown in the diagram. Use glue and finishing nails to lock the trims into place. Align the edges for a professional result.

Fitting the shelves

Fitting the shelves

Cut the shelves for the tool stand from 3/4″ plywood. Fit the shelves to the supports, as shown in the diagram.

Attaching the trims to the front of the tool stand

Attaching the trims to the front of the tool stand

Fit 1×3 trims to the front face of the tool stand, as shown in the diagram. Use 1 1/4″ brad nails to secure the trims to the shelves.

Fitting the tabletop

Fitting the tabletop



Fitting the trims to the countertop

Fitting the trims to the countertop

One of the last steps of the project is to attach the 1×2 or 1×3 trims to the exterior of the countertop. As you can easily notice in the diagram, you should cut both ends of the trims at 45 degrees. Use glue and 1 1/4″ brad nails to lock them into place.

Fitting the caster wheels

Fitting the caster wheels

Attach caster wheels to the bottom of the tool stand, as shown in the plans. Use 2″ caster wheels to get a professional result.

Tool Stand Plans

Tool Stand Plans

I hope you enjoyed this this step by step tutorial and you should take a look over the rest of my projects. I would love to hear your feedback and to see your pins, likes and shares. If you build this tool stand don’t forget to send a few pics. If you want to protect them from decay.



Thank you for reading our project about tool stand plans and we recommend you to check out the rest of the projects. Don’t forget to SHARE and LIKE our projects with your friends, by using the social media widgets, if you want to help us keep adding free woodworking plans.
