Sideboard plans

by Jack Sander
0 comments 257 views 6 minutes read



This step by step diy woodworking project is about sideboard plans. If you want to learn more about building a wooden sideboard with a neat design, we recommend you to pay attention to the instructions described in the article. There are many plans and designs to choose from, so make sure you take a look over the rest of the woodworking projects described in the article.

Before starting the actual construction project, we recommend you to plan everything, as to save money and to keep the costs under control. Adjust the size and the design of the sideboard to suit your needs. In addition, we recommend you to invest in high-quality materials, such as pine, redwood or cedar, as they have a nice finish and are highly durable, especially in a humid environment.

If you don’t have a rich expertise in woodworking field, you should ask a friend to give you a hand with the project. There are many things that you could go wrong, so make sure you plan everything and invest in quality materials. Select the lumber with attention, making sure the components are perfectly straight and in a very good condition. Use a carpentry square to check if the corners are right-angled. See all my Premium Plans in the Shop.



Made from this plan

Add-Image



Sideboard plans

Building a sideboard

Building a sideboard



Materials

  • A – 2 pieces of 3/4″ plywood – 17 3/4″ x 28 1/2″ long, 1 piece – 18 1/2″ x 42″ long FRAME
  • B – 5 pieces of 3/4″ plywood – 28 1/2″ x 40 1/2″ long BACK
  • C – 2 pieces of 1×3 lumber – 28 1/2″ long, 2 pieces – 37″ long, 1 piece of 1×2 lumber – 23 1/2″ long FRONT TRIMS
  • D – 4 pieces of 2×2 lumber – 4″ long, 2 pieces of 1×2 lumber – 15 1/2″ long, 2 pieces – 39″ long BASE
  • E – 1 piece of 3/4″ plywood – 19 1/4″ x 43 1/2″ long, 2 pieces of 1×1 lumber – 19 3/4″ long, 1 piece – 43 1/2″ long TOP
  • F – 2 pieces of 1×2 lumber – 23 1/4″ long, 2 pieces – 14 1/2″ long, 1 piece of 1/4″ plywood – 15″ x 20 3/4″ long 2xDOOR

  • 2 pieces of 1×3 lumber – 8 ft
  • 4 pieces of 1×2 lumber – 8 ft
  • 1 piece of 3/4″ plywood – 4’x8′
  • 1 piece of 1/4″ plywood – 2’x2′
  • 1 piece of 2×2 lumber – 2 ft
  • 1 piece of 1×1 lumber – 8 ft
  • hinges
  • 2 1/2″ screws
  • 1 1/4″ screws
  • glue, stain
  • wood filler

Tools

  • Safety gloves, glasses, Miter saw, jigsaw
  • Chalk line, tape measure, spirit level, carpentry pencil
  • Drill machinery and drill bits

Tips

  • Apply several coats of wood stain to the wooden components
  • Fill the holes with wood filler and smooth the surface

Time

  • One Day

Related





Building a sideboard

Building the frame of the sideboard

Building the frame of the sideboard



First of all, we recommend you to build the main frame of the sideboard. Therefore, we recommend you to cut the components out of 3/4″ plywood. Draw the mark lines on the plywood sheets and get the job done with a proper circular saw. Smooth the edges with sandpaper and drill pocket holes along the top and bottom of the side components. Align the components with great care, making sure the edges are perfectly flush. Insert a few 1 1/4″ screws to create rigid joints.



Attaching the back

Attaching the back



Build the back of the sideboard out of 3/4″ plywood and smooth the edges with attention. Drill pocket holes along the four edges and fit the components to the back of the sideboard. Add glue to enhance the bond and check if the corners are square.



Attaching the face

Attaching the face



Next, attach the trims to the front face of the sideboard. Before attaching the trims to the front face of the sideboard, we recommend you to lock them together tightly. Drill pocket holes at both ends of the horizontal components and secure them to the side trims. Afterwards, drill pocket holes at both ends of the middle trims and secure it to the top and bottom trims by using 1 1/4″ screws. Add glue to the joints and leave no gaps between them.



Building the base of the sideboard

Building the base of the sideboard



Next, build the base for the sideboard as described in the diagram. Use 2×2 lumber for the legs and 1×2 lumber for the rest of the frame. Drill pocket holes at both ends of the supports and secure them to the legs by using 1 1/4″ screws. Add glue to the joints and make sure the corners are square.



Attaching the base

Attaching the base



Lay the base to the bottom of the sideboard and make sure the edges are perfectly aligned. Drill pocket holes through the supports and insert 1 1/4″ screws into the sideboard, as to create a rigid structure.



Attaching the top

Attaching the top



Build the top of the sideboard out of 3/4″ plywood and secure it to the frame of the sideboard by inserting 1 1/4″ screws through the frame. Center the frame of the sideboard to the top component and leave no gaps between them.



Building the door frames

Building the door frames



Build the frame of the doors out of 1×2 lumber. Drill pocket holes at both ends of the horizontal components and secure them to the vertical supports by using 1 1/4″ screws. Add glue to the joints and make sure the corners are square. Use a router to make 1/4″ x 1/4″ rabbets to the interior faces of the doors, as described in the diagram.



Fitting the door panels

Fitting the door panels



Use 1/4″ glass or 1/4″ plywood to make the door panels. Fit the components to the frame of the doors and lock them into position by using finishing nails and glue or silicone. Make sure the edges are flush before locking the panels into place.



Fitting the trims

Fitting the trims



Fit 1×1 decorative trims under the top of the sideboard. Cut the joint ends at 45 degrees and lock them to the sideboard using finishing nails and glue. Leave no gaps between the components and make sure the edges are flush.



Fitting the doors

Fitting the doors



Fit the doors to the door  openings and secure them into place with appropriate hinges. Fit handles to the doors and make sure they open and close properly.



Sideboard plans

Sideboard plans



Last but not least, we recommend you to take care of the finishing touches. Fill the holes with wood filler and let it to dry out for several hours. Afterwards, smooth the wooden surface with fine-grit sandpaper and vacuum the residues.

Smart tip: Apply several coats of stain or paint to the wooden components, if you want to protect them from decay and to enhance the look of the sideboard.





Thank you for reading our project about sideboard plans and we recommend you to check out the rest of the projects. Don’t forget to share our projects with your friends and LIKE us, by using the social media widgets, if you want to be the first that gets our latest articles.
