Mirror coat rack plans

This step by step diy woodworking project is about mirror coat rack plans. If you want to learn more about building a simple coat rack with mirror, we recommend you to pay attention to the instructions described in the article. There are so many designs and plans to choose from when building coat racks, so make sure you take a look over the related woodworking projects that are featured on our site.

Before starting the actual construction project, we recommend you to plan everything, as to save money and to keep the costs under control. Adjust the size and the design of the coat rack to suit your needs. In addition, we recommend you to invest in high-quality materials, such as pine, redwood or cedar, as they have a nice finish and are highly durable, especially in a humid environment.

If you don’t have a rich expertise in woodworking field, you should ask a friend to give you a hand with the project. There are many things that you could go wrong, so make sure you plan everything and invest in quality materials. Select the lumber with attention, making sure the components are perfectly straight and in a very good condition. Use a carpentry square to check if the corners are right-angled. See all my Premium Plans in the Shop.

Made from this plan

Building coat rack

Materials

A – 2 pieces of 1×3 lumber – 35″ long, 2 pieces of 1×6 lumber – 28 1/2″ long FRAME
B – 2 pieces of 1×2 lumber- 46″ long, 2 pieces – 25 1/2″ long SUPPORTS
C – 1 piece of 1×4 lumber – 28 1/2″ long, 2 pieces – 4 3/4″ long SHELF
D – 3 pieces of coat hooks HOOKS
E – 1 piece of 1/4″ mirror – 24″ x 35 1/2″ long MIRROR

1 piece of 1×3 lumber – 6 ft
1 piece of 1×6 lumber – 6 ft
1 piece of 1×2 lumber – 8 ft
1 piece of 1×4 lumber – 3 ft
mirror
1 1/4″ screws
glue, stain
wood filler

Tools

Safety gloves, glasses
Miter saw, jigsaw
Chalk line, tape measure, spirit level, carpentry pencil
Drill machinery and drill bits

Tips

Apply several coats of wood stain to the wooden components
Fill the holes with wood filler and smooth the surface

Time

One Day

Coat Rack Plans
Hall Tree Plans

Building a mirror coat rack

Building the frame of the mirror

The first step of the woodworking project is to build the frame of the mirror coat rack. As you can easily notice in the diagram, you need to build the vertical supports out of 1×3 lumber and the horizontal supports out of 1×6 lumber. Drill pocket holes at both ends of the vertical supports and secure them to the perpendicular components using 1 1/4″ screws. Add glue to the joints and remove the excess with a damp cloth. Use a router to make 1×4″ x 1/4″ rabbets to the interior face of the frame.

Fitting the back supports

The next step of the indoor woodworking project is to attach 1×2 supports to the back of the frame. In order to get a professional result, we recommend you to assemble the 1×2 frame using galvanized screws and glue. Drill pocket holes at both ends of the horizontal components and secure them to the vertical supports. Make sure the corners are square and leave no gaps between the components.

Fitting the mirror

Fit the mirror to the frame and lock it into place using appropriate clips. Work with attention and make sure the edges are flush.

Fitting the shelf supports

Continue the woodworking project by attaching the shelf supports to the bottom of the wooden frame. Mark the cut lines on a piece of 1×4 lumber and get the job done with a jigsaw. Smooth the curved edges with fine-grit sandpaper and remove the residues with a damp cloth. Drill pocket holes and attach the supports to the frame using 1 1/4″ screws and glue. Leave no gaps between the components.

Fitting the shelf

Build the shelf out of 1×4 lumber and fit it to the supports, making sure both edges are perfectly aligned. Drill pocket holes along the top of the supports and insert 1 1/4″ screws to create a rigid bond between the components. Add glue to the joints.

Fitting the hooks

Attach the hooks to the bottom of the wooden rack, making sure you place them equally-spaced. Choose an appropriate design that matches the style of the rest of the furniture in your home.

Mirror Coat Rack Plans

Last but not least, we recommend you to take care of the finishing touches. Fill the holes with wood filler and let it to dry out for several hours. Afterwards, smooth the wooden surface with fine-grit sandpaper and vacuum the residues.
