How to build a farmhouse bench

This step by step woodworking article is about how to build a farmhouse bench. If you want to enhance the look of your living room, a rustic farmhouse table with two benches will add character to your home. Taking into account that it is quite hard to find this kind of furniture on the market, the only alternative is to get the job done by yourself. Even if it might look a complex job, any amateur do-it-yourselfer can do the job, if the right plans and carpentry techniques are used.

Buy quality lumber to make the farmhouse bench, as you need to obtain a piece with a nice appearance. Make a list will all the materials required for the project and buy them from the store with the best offer in terms of price and quality. Redwood, cedar or pine boards are good choices for this project, as they are durable and have a beautiful look. Make sure the boards are perfectly straight and don’t have any kind of visible flaws, such as chips, dents or twists.

Pre-drill holes in the wooden components before inserting the screws, if you want to prevent the wood from splitting. Align the components and plumb them with a spirit level, before locking them temporarily with a couple of C-clamps. Add a wood glue to the joints, if you want to enhance the rigidity of the joints. Work with great attention, if you want to obtain a professional result. Any amateur handyman can get the job done in just a weekend, if the right plans and carpentry techniques are used.



Made from this plan

Add-Image



Building a wooden bench

Building a wooden bench

Building a wooden bench



Materials

  • 4 pieces of 4×4 lumber – 17″ long LEGS
  • 2 pieces of 2×4 lumber – 12 1/2″ long BRACES
  • 2 pieces of 1×3 lumber – 59 1/2″ long, 2 pieces – 12 1/2″ long, 7 pieces – 11″ long FRAME
  • 2 pieces of 2×6 boards – 16 1/2″ long, 3 pieces – 64″ long SEAT
  • 2 1/2” and 3″ wood screws – SCREWS



Tools

  • Safety gloves, glasses
  • Miter saw saw, jigsaw
  • Chalk line, tape measure, spirit level, carpentry pencil
  • Drill machinery and drill bits
  • Router, 1/4” round bit
  • Pocket hole jig



Tips

  • Pre-drill holes in the wooden components, before driving in the screws
  • Smooth the exterior edges of the components, by using a router with a 1/4” bit



Time

  • One weekend





How to build a farmhouse bench

Building the posts of the bench

Building the posts of the bench



Build the four legs of the wooden bench, as in the plans. Use 4×4 lumber or join together two pieces of 2×4 lumber together. Afterwards,  notch the legs, as in the image, ensuring you don’t damage the lumber.

Smart Tip: You could adjust the size of the legs, according to your needs. Buy perfectly straight lumber, in order to obtain a professional result. Clean the recess thoroughly, using a chisel and a sandpaper.



Installing the braces

Installing the braces



The next step of the project is lock the two ends of the bench together, using 2×4 braces. First of all, you need to place the legs on a level surface and align them properly. Next, measure the diagonals and adjust their position, until they are equal.

The supports should be oriented towards the inside of the table, if you want to obtain a nice appearance. Drill pilot holes in the braces and insert 2 1/2” screws, making sure you countersink the head of the screws.



Building the frame of the bench

Building the frame of the bench



Afterwards, you have to build the frame of the bench and to secure it to the legs, using 2” screws. As you can see in the image, you should build the frame using 1×3 or 2×3 lumber. Using the 2×3 will make the bench rigid, but it will also be heavier.

Plumb the sides of the bench with a spirit level, and make sure the frame is horizontal. Use pocket holes to join the side aprons to the end aprons. Add glue to the joints to enhance the bond.



Installing the top supports

Installing the top supports



The next step is to install the seat supports, making sure you place them equally spaced, as in the plans. Leave about 6-8” between the supports and lock them into place with 2” screws. Work with good judgement if you want to obtain a professional result.

Smart tip: Drill pilot holes in the side aprons, before driving in the screws in the wooden supports. Use a spirit level to make sure the whole surface is perfectly horizontal.



Building teh top of the bench

Building teh top of the bench



Next, you need to secure the ends slats into place and to lock them with 3” wood screws. The slats should overhang, about 2” in all directions. Add a good wood glue to the joint, to increase the rigidity of the frame.

The best way to secure the rest of the slats into place is to drill wood screws trough the seat supports in the slats. In order to get access to the slats, you need to turn the bench upside-down.



Securing the top of the bench

Securing the top of the bench



Drill pilot holes trough the supports and drive in 3” wood screws, as in the image. Make sure the slats are aligned at all ends and there are no gaps between them, before inserting the screws.

Smart tip: Make sure the wooden bench has a symmetrical look, otherwise the end result might not raise up to your expectations. Clean the excess glue with a damp sponge, before it dries out.



How to build a farmhouse bench

How to build a farmhouse bench



After assembling the wooden components together, you need to take care of the finishing touches. Therefore, fill the holes with a good wood putty and let the compound to dry out properly for several hours.

Smart tip: Sand the wooden surface with 120-grit sandpaper, making sure the bench has a nice appearance. Apply several coats of stain, in order to protect the lumber from rot.





Thank you for reading our article about how to build a farmhouse bench and we recommend you to check out the rest of our projects. Don’t forget to share our projects with your friends, by using the social media widgets.
