2×4 Full Size Bed Plans

This step by step diy article is about basic platform bed plans. I have designed this super simple platform bed frame so you can build it in one single day using basic tools and materials. In addition, considering queen size if the most common dimension I’ve decided to create the plan with those dimensions in mind. This will be a budget friendly project, but I still added a decorative headboard to make the bed full of style.

Always aligned the components before locking them together with screws. In addition, we recommend you to pre-drill the lumber, otherwise the wood might easily split. Add glue to the joints, if you want to enhance their bond. Smooth the cut edges with fine grit sandpaper and remove the residues using a vacuum cleaner. Make sure you take a look over the related plans to get an idea about what you can build for your home.



Made from this plan

Add-Image



2×4 Full Size Bed Plans

Building a 2x4 full size bed

Building a 2×4 full size bed



Materials

  • A – 2 pieces of 2×4 lumber – 11 1/2″ long, 1 piece – 51″ long FOOTBOARD
  • B – 2 pieces of 2×4 lumber – 33″ long, 2 pieces – 55″ long, 9 pieces – 18″ long, 1 piece – 64″ long HEADBOARD
  • C – 2 piece of 2×4 lumber – 76″ long SIDES
  • D – 3 pieces of 2×4 lumber – 76″ long, 1 piece – 8″ long CLEATS
  • E – 13 pieces of 1×4 lumber – 55″ long  SLATS

Tools

Tips

  • Pre-drill holes in the wooden components, before driving in the screws
  • Smooth the exposed edges, by using a router with a 1/4” bit

Time

  • One day

Related





Make sure you follow me on YOUTUBE and Facebook to be the first that gets our latest plans and for some other exclusive content. Also, follow me on Pinterest to get many ideas for your backyard from all the internet! See how you can Support Me with no extra costs to you.





Building a 2×4 full size bed

Footboard - Full size bed

Footboard – Full size bed

The first step of the project is to build the footboard for the full size bed frame. Therefore, cut the components at the right size from 2x4s. Drill pocket holes at both ends of the horizontal support and insert 2 1/2″ screws into the legs. Align the edges with attention and make sure the corners are square.

Assembling the frame of the headboard

Assembling the frame of the headboard

Next, you need to build the frame for the headboard. Cut the components as shown in the diagram and lay them on a level surface. Drill pocket holes at both ends of the horizontal supports and insert 2 1/2″ screws into the legs. Check if the corners are square and align the edges flush.

Fitting the slats to the headboard panel

Fitting the slats to the headboard panel

Next, fit the slats to the headboard frame. Drill pocket holes at both ends of the slats and insert 2 1/2″ screws to lock them to the frame. Place a 2 1/4″ wood block between the slats to create even gaps.

Fitting the top trim to the headboard

Fitting the top trim to the headboard

Center the 2×4 trim to the top of the headboard, leaving 1″ on all sides. Drill a pilot hole and insert 2 1/2″ screws to lock it into place tightly.

Fitting the sides

Fitting the sides

Next, you need to join the two boards by fitting the side supports. Drill pocket holes at both ends of the supports and insert 2 1/2″ screws. Place the supports with the pocket holes facing inward. Make sure the edges are flush and if the corners are square.

Fitting the cleats

Fitting the cleats

Use 2×4 lumber for the bed frame cleats. Drill pocket holes and insert 2 1/2″ screws to lock the cleats to the bed frame.

Fitting the middle leg

Fitting the middle leg

Fit the 2×4 leg to the middle cleat. Drill pilot holes and insert 2 1/2″ screws to secure it into place tightly.

Fitting the slats

Fitting the slats

Attach the 1×4 slats to the top of the cleats. Cut a wood block at 2 1/2″ and then fit it between the slats, as spacer, to create even gaps. Use 1 5/8″ screws to secure the slats to the cleats, after drilling pilot holes.

2x4 Full size Bed Plans

2×4 Full size Bed Plans

Fill the holes with wood putty and then smooth the surface with 120-220 grit sandpaper. Apply a few coats of paint/stain over the components to protect them from decay and to enhance the look of the bed frame. Check out PART 2 of the project, so you learn how to build the modern headboard.

2x4 Full size Bed Plans - side view

2×4 Full size Bed Plans – side view

Make sure you check out my other bed frame plans, as I have an extensive palette of free plans available on this blog. In addition, make sure you check out all my indoor plans HERE.

Smart Tip: Clean the residues with a dry cloth, before staining the platform loft bed with the appropriate products for your tastes and needs. Afterwards, install the mattress and take a nap.





Thank you for reading our article about basic queen size platform bed plans and we recommend you to check out the rest of our home improvement projects. Don’t forget to share this projects to your friends, using the social media widgets, if you’ve found it useful. Like us on Facebook to be the first that gets the latest updates and to help us create more free plans for you.
